ANSI Bellow Valve

API 602 Bellow Gate Valve

Size range : 1/2"-2"
Class: 150LB-1500LB
Temperature : ≤425 ℃
Materials :A105,LF2,F5,F11,F22,F304,F316,F316L,F321,F347

Features and benefits

● A compact but extremely sturdy design for high pressure-temperature service.
● Solid CoCr alloy wedge (optional) ensures low friction and long service life.
● For Class 1500 valves and for steam service, seats are seal-weldedto the body.
● Packing rings are precompressed to 4000 psi to provide a high integrity seal.
● For welded bonnet valves, the bonnet is threaded in and torqued to an engineered torque value and the body bonnet joint is strength-welded, offering double protection against leakage. (Body/bonnet threads and strength-weld).
● Fully guided wedge reduces wear on seating surfaces.
● Repairable 2-piece stem drive.
● Parallel slide gate valves also available.
● Optional design available with double packing, leak-off connection, live-loading and a packing blowout for easy removal of old packing.

Technical specification:

●Design: API 602,BS5352,ANSI B16.34

●Connection ends:

   a.Scoket welded ends conform to ANSI B16.11;GB/T1751

   b.Screw ends conform to ANSI B1.20.1;GB/T7306

   c.Butt-welded ends conform to ANSI B16.25;GB/T12224

   d.Flanged ends conform to ANSI B16.5;GB/T79

●Test & inspection: API 598; GB/T13927

●Structure feature:

   Bolted bonnet, outside screw and yoke.

   Welded bonnet,outside screw and yoke.
